ELECTRO-MECHANICAL BARRIER GATE SYSTEM


Heavy duty electro-mechanical system designed for residential,
commercial or industrial's traffic flow management.
Solid and Long Lasting

STURDY AND STRONG HOUSING

ITALIAN
TECHNOLOGY

AC based torque motor is strong and maintainance free. Compressed counter balance spring avoid possibility of it being over-stressed and break due to high volumes of open/close operations.

2.5mm thickness mild steel. Housing is
phosphate-coated and further coated with
plastic to maintain its color tone

LIMIT SWITCH

Smart sensor auto detects open/close positions for higher accuracy.
Unique lever design and smart motor control allow swift arm movements that reduce bouncing at end position

SAFETY CLUTCH

Clutch can be conveniently released without opening casing.
Arm can be easily lifted or closed by hand after clutch is released. Intuitive control with three separate inputs for the arm (up, stop and down)

SAFETY REVERSE

Arm will automatically 'fall out' if hit by object to avoid damaging both the object and the arm.

SAFETY REVERSE

Arm will auto-reverse when it hits and obstacle during closing, Arm is self-locked in any position to avoid adjusting arm manually.

SAFETY REVERSE

Internal parts in housing are protected by cam lock to avoid tampering. Built-in MCB to protect against electrical hazards.

PICK YOUR SIZE

Length of the Barrier gate

3 m

4 m

6 m

SPECIFICATIONS

Backup Battery
12V 7AH
Heavy Duty
24 hr continous use
Auto Close
On adjustable timer
Simple interface for proximity
cards & loop detectors
Controller
1+3 Remote
Warranty
1 year
Flexible arm holder with clips
Allow arm to swing out easily when hit a car
Articulated arm
available
Arm Barrier Length
3M / 4M / 5M / 6M
Key release for
manual operation
Power Supply
24V DC Plug Pack
Motor Power
250W
Opening Speed
2-8 Second
Kit Weight*
55kg
