POWDER COATING TECHNOLOGY
Powder coating technology prevents possible rusting and maintaining the look of the prodcut to prevent counterfit replacements.
INTRODUCING OUR NEW
Self-installed Auto Gate System
NO WELDING
REQUIREMENT
Brackets and accessories are specially made to install with bolts and nuts.
EASY & READY FOR INSTALLATION
Our special designed brackets ables to help you install your autogate opener system within a quick time.
Control boards, transformers and receivers are wired and installed in the given control box.
Solid and Long Lasting
3-STAGE PLANETARY MOTOR
ITALIAN
TECHNOLOGY
The gears of the 3-stage planetary motor are built with black steel, operated with 12-14 small, strong gears. These premium materials increase lifespan & durablity of the motor system. The state-of-the-art system ensures smooth and stable operation for your gate at all times.
Arm actuators are made from aluminium alloy
and hard stainless steel
and hard stainless steel
POWER BACK-UP SYSTEM
Even when power trip occurs, the gate system will still
be functional for up to 48 hours.
STABLE
RDS 9 are able to protect your motor by strongly holding your gate if the gate faces aggressive shaking.
HEAT-PROOF
With the heat-proof grease specially applied on our DC mini motors, it prevents motors from overheating.
RDS 3 Could Lift Up to 14ft max Gate Width
SPECIFICATIONS
Country
Italy technology enhancement
Gate size (one side of the gate)
Size 7"-9" (M) Size 9"-13" (L)
Customized gates suitability
Heavy-profile
DC motor
3 stage planetary gear
Controller
1+3 Remote
3-Speed Control Board
Big Control Board
Battery
12V 7AH
Back-up system
Up to 48 hours
Backup Battery
12V 7AH
Temperature
0° C to + 80° C
Main Supply
AC230V, 50Hz
Driving Method
Screw Driven Piston Type
Operating
DC24v for Normal Speed
DC12v for Cushioning Speed
Max. Output Power
80W per Driver
Piston
Max. Stroke : 31cm
Max. Speed : 2.2cm/sec.
Operation Cycle
14 second per 90° C (approx)
Position Limit Device
Electronic Fuzzy Logic
Gearbox
Rotary Planetary Reducer
Gate type
Safety Clutch
Electronic Current Sensing
Electronic Controller
Microcomputer Based
Remote Controller
UHF Digital PWM Type
